cs 512 - computer vision

Cameras and computers are everywhere. Can we make computers see? Can we make computers respond to our behavior? Automated sensing by computers is a key element in ubiquitous computing. Similar to the importance of vision in humans, cameras are the most eminent sensors computers may have. By using cameras, computers can interact with people, inspect and monitor various processes, and identify people and behavior. Computer vision is a rapidly evolving field of study in computer science which is facilitated by recent years developments in computing hardware. Advanced computer hardware is now a standard component in off the shelf PCs, and digital cameras are cheap and abundant. The consequence of which is a surge in graphics and imaging applications. Computer vision aims at the analysis of the real world based on images captured by one or more cameras or similar sensory data for various purposes. Such analysis is a common practice in industrial, medical, military, and scientific applications such as product inspection and quality control, surveillance and monitoring, automated recognition of objects, robot guidance, human motion tracking, document/handwriting analysis, and augmented and virtualized reality. Topics to be covered by the cs512 course in this semester include: overview of computer vision and related areas, extraction of features from images, probabilistic modeling in images, camera calibration, epipolar geometry estimation, statistical estimation, model reconstruction from images, statistical filtering and tracking in video sequences, motion estimation in video sequences, optical flow, and object recognition. The course serves as a good starting point for graduate students interested in getting acquainted with the area of computer vision as well as for students interested in pursuing the area of visual computing in greater detail. The course assumes a basic knowledge of calculus and linear algebra and some programming experience. Programming assignments in the course will use the OpenCV standard to support capturing and manipulation of images and videos. For further details please refer to the course website or contact the course instructor.

Instructor

Gady Agam
SB 237e, x7-583
Office hours:
Tuesday, Thursday
6:30-7:30pm



TA

Xu Ouyang
SB-115, x7-5705
Office hours:

Tuesday, Thursday
10:00am-12:00pm

Sections

CS-512-01:  (SB-204)

CS-512-02:  (Internet)

CS-512-03:  (Internet)


Class hours:
Tuesday, Thursday
5:00-6:15pm


Syllabus



Course outline


What to expect from this course


Computer vision can be covered at different levels. The focus of this course is the understanding of algorithms and techniques used in computer vision. Students in the course are expected to write computer programs implementing different techniques taught in the course. The course requires mathematical background and some programming experience. This course does not intend to teach how to use a specific application software.



Objectives


  1. Introduce the fundamental problems of computer vision.
  2. Provide understanding of techniques, mathematical concepts and algorithms used in computer vision to facilitate further study in this area.
  3. Provide pointers into the literature and exercise a project based on a literature search and one or more research papers.
  4. Practice software implementation of different concepts and techniques covered in the course.
  5. Utilize programming and scientific tools for relevant software implementation.



Overview


  1. Introduction: overview of computer vision, related areas, and applications; overview of software tools; overview of course objectives.; introduction to OpenCV.
  2. Image formation and representation: imaging geometry, radiometry, digitization, cameras and projections, rigid and affine transformations.
  3. Filtering: convolution, smoothing, differencing, and scale space.
  4. Feature detection: edge detection, corner detection, line and curve detection, active contours, SIFT and HOG descriptors, shape context descriptors.
  5. Model fitting: Hough transform, line fitting, ellipse and conic sections fitting, algebraic and Euclidean distance measures.
  6. Camera calibration: camera models; intrinsic and extrinsic parameters; radial lens distortion; direct parameter calibration; camera parameters from projection matrices; orthographic, weak perspective, affine, and perspective camera models.
  7. Epipolar geometry: introduction to projective geometry; epipolar constraints; the essential and fundamental matrices; estimation of the essential/fundamental matrix.
  8. Model reconstruction: reconstruction by triangulation; Euclidean reconstruction; affine and projective reconstruction.
  9. Motion analysis: the motion field of rigid objects; motion parallax; optical flow, the image brightness constancy equation, affine flow; differential techniques; feature-based techniques; regularization and robust estimation; motion segmentation through EM.
  10. Motion tracking: statistical filtering; iterated estimation; observability and linear systems; the Kalman filter; the extended Kalman filter
  11. Object recognition and shape representation: alignment, appearance-based methods, invariants, image eigenspaces, data-based techniques.
  12. Final presentation: students present selected topics and develop software implementation of related techniques based on the review of relevant literature. The work should be summarized in a concluding report which should include simulation results. A list of possible topics will be advertised prior to the project selection due date.




Grading

component
description
weight
participation
up to 4 unjustified missed classes and all quizes  ⇒  full credit
5%
assignments
TBD
25%
project
presentation (5%) project (15%)
20%
midterm exam
open notes (4 paper pages)
10%
final exam
open notes (8 paper pages)
40%
total

100%



  1. There is an additional mandatory assignment (assignment 0) which does not carry any credit. There is a penalty of 5% for not submitting this assignment.
  2. A certain percentage of the students may be invited to discuss their assignments.
  3. Late days: there is a total of 4 "late days" for all the assignments. After that 1 late day = -10%. Late days do not include weekends and university holidays. The final project can not be late. Assignments can not be submitted after classes end.
  4. Each member of this course bears responsibility for maintaining the highest standards of academic integrity. All breaches of academic integrity must be reported immediately. Copying of programs from any source (e.g. other students or the web) is considered to be a serious breach of academic integrity.



Books


  1. Computer Vision: Algorithms and Applications, R. Szeliski, Springer, 2011.
  2. Computer Vision: A Modern Approach, D. Forsyth and J. Ponce, Prentice Hall, 2nd ed., 2011.
  3. Introductory techniques for 3D computer vision, E. Trucco and A. Verri, Prentice Hall, 1998.



Tentative schedule


class date topic assignment




1 08/29 Introduction AS0
2 08/31

3 09/05 Geometric image formation
4 09/07

5 09/12 Filtering AS1
6 09/14

7 09/19

8 09/21 Feature detection
9 09/26

10 09/28
AS2
11 10/03 Object recognition
12 10/05

13 10/10

14 10/12 Midterm exam (SB 104)

15 10/17 Camera calibration PROJ
16 10/19

17 10/24

18 10/26 Multiple view geometry AS3
19 10/31

20 11/02

21 11/07 Motion and tracking
22 11/09
AS4
23 11/14

24 11/16 Project presentations
25 11/21

26 11/23 No class (Thanksgiving) AS5
27 11/28

28 11/30

29 12/05 Final exam: 5:00pm-7:00pm     SB111


Lectures


Videos of lectures

Videos of lectures are available through blackboard




    Reading materials


Topic Reading
Introduction to computer vision Ch. 1
Image formation
Ch. 2
Filtering Ch. 3
Feature detection
Ch. 4
Segmentation Ch 5
Camera calibration
Ch. 6
Epipolar geometry
Ch. 11
Model reconstruction
Ch 7
Motion analysis
Ch. 8
Recognition
Ch. 14

Assignments


For additional instructions/ hints check the FAQ page

Please submit assignments via blackboard


Assignment Description Data Weight Due date
assignment 1 Image formation
images
4% 9/26
assignment 2 Filtering
images
4% 10/9
assignment 3
Feature detection
images
4%
10/19
assignment 4
Camera calibration
calibration data
4%
assignment 5
Stereo vision
stereo pairs
matched points
4%
assignment 6
Motion analysis
video sequences
5%
project presentation (5%)
project (15%)
 N/A  20% (proposal 10/26 )
(final submission 11/15 )



Additional assignments:



Additional information:


Faq





Q1: C++ IDE



Q1.1: Instructions for downloading MS visual studio for Windows


  • Download MS Visual studio from here

Q1.2: Instructions for installing DEV-C++ for Windows


Install the latest Dev-C++  package

Q1.3: Instructions for installing IDE for Linux


Download one of the following Code::BlocksEclipseNetBeans


Q2: OpenCV



Q2.1 Installing OpenCV in windows


  1. Download OpenCV from sourceforge
  2. Execute the file you downloaded and follow the instructions
  3. For additional help read the installation guide

Q2.2 Using OpenCV in windows


  1. Read the OpenCV notes on creating a new OpenCV project
  2. Additional instructions for VS.NET (old)


Q2.3 Specifying the location of DLL files if the compiler cannot find them in windows


    Option 1:
                    •           Add to the PATH environment variable the path to C:\Program Files\OpenCV\bin
                        1.           Follow the instructions in the following figure
                        •     Option 2:
                        1.          Edit the file C:\AUTOEXEC.BAT and add the following line to it:
                        2.          set PATH=%PATH%;C:\Program Files\OpenCV\bin;
                        3.          Reboot your computer
                    •     Option 3:
                      1.          Copy all the DLL files from C:\Program Files\OpenCV\bin to C:\WINDOWS\system32 and/or C:\WINDOWS\system
                    •     Option 4:
                      1.          Copy all the DLL files from C:\Program Files\OpenCV\bin into the directory where your program resides

Q2.4 Installing OpenCV in Linux


  1. Download the source code from sourceforge
  2. Read the installation guide


Q2.5 Using OpenCV in Linux


  1. Compile the program using
          g++ prog.cpp -o prog `pkg-config --cflags --libs opencv`



Q3: wxWidgets



Q3.1: Instructions on how to use wxWidgets in Visual C++


Install wxpack (wxWidgets v2.8.12)
Create an empty win32 console project, change the following property of the project:

  Configuration Property - C/C++ - General - Additional Include Directories

    %InstalledPath%\wxWidgets-2.8.12\include
    %InstalledPath%\wxWidgets-2.8.12\lib\vc_lib\mswd

  Configuration Property - Linkers - General - Addtional Library Directories

    %InstalledPath%\wxWidgets-2.8.12\lib\vc_lib

  Configuration Property - Linkers - Input - Additional Dependancies

    comctl32.lib rpcrt4.lib winmm.lib advapi32.lib wsock32.lib wxbase28d.lib wxmsw28d_core.lib wxmsw28d_gl.lib wxjpegd.lib wxpngd.lib wxregexd.lib wxtiffd.lib  wxzlibd.lib wxexpatd.lib

  Code Generation - Runtime Library


    Multi-threaded Debug (/MTd)

  Linker - System

    Window (/SUBSYSTEM:WINDOWS)

  Build Events - Post Build Events ( this starts a command line window together with your wxwidgets frame)

    editbin $(TargetPath) /SUBSYSTEM:CONSOLE

 Q3.2: Instructions on how to use wxWidgets in Linux


    Compile the source or install the appropriate package.
    Compile with the following flags: `wx-config --cxxflags`
    Link with the following libraries: `wx-config --libs` -lwx_gtk2_gl-2.8

Q3.3: Specific problems with wxWidgets

  1.   Conversion between wxString and a normal string:   http://wiki.wxwidgets.org/WxString
  2.   Global Keyboard events in wxWidgets:   http://wiki.wxwidgets.org/Catching_key_events_globally
